Elektrinio dviračio variklis

Elektrinis dviračio variklis su akumuliatoriumi ir krovikliu. Nauja elektrinė dalis su ratu. Vedantis priekinis ratas (ne kinietiškas), saugus, 24 colių.
Baterija: 36V 13Ah (470Wh) - 100 km (62 miles) Max Range
Maksimalus greitis: 32km/h
Maksimalus nuvaziuojamas atstumas: 100km
Vidutins nuvaziuojamas atstumas 65km
Atstumas nuvaziuojamas vien naudojant elektriniu varikliu: 50km
BATTERY
Battery Chemistry LiMn2O4 Lithium Ion
Nominal Battery Voltage 36V
Charged Battery Voltage 42V
Battery Capacity 13Ah
Nominal Battery Energy 470Wh
Battery Removable Yes
Battery Cell Type 18650
Cell Spec Samsung ICR18650-26F 2600mAh
Cell Configuration 10S 5P
Built in BMS Yes
Other Features USB charging, battery cradle included
Maximum Battery Charge Cycles 1,000
Battery Charger Type SANS 36V 2A Smart charger
Battery Charge Time 6.5 hours from empty
MOTOR
Motor Brand Shengyi OEM for Dillenger
Motor Model DGW07
Motor Voltage 36V
Max Motor Power 250W
Drive Type Geared hub drive
Motor Sensors Hall sensor
CONTROLLER
Controller Brand Dillenger OEM Sinewave with stealth cradle mount
Controller Operating Voltage 36V
Controller Max Voltage 50V
Controller Low Voltage Cutoff 30V
Controller Operating Amps 7-15A
Controller Nominal Power Output 250W-350W
Controller MOSFET Tubes 6
Controller Sensors Hall sensor]
WEIGHT
Total Weight - No Battery 4.5kg (9.9lbs)
Battery Weight 3.2kg (7.1lbs)
Total Weight 7.7kg (17lbs)
GENERAL
Battery Width 82mm (3.2")
Battery Length 360mm (14.1") including cradle, 315mm (12.4") without
Battery Height 125mm (4.9")
